Categories: Electronic Manufacturing Services
Sub Category: EMS
Material: Plastic
Model Name : Intel S7100 Chipset : Intel® C621 PCH (LBG-1G) Memory • (6+6) DDR4 DIMM slots (w/6x memory channels per CPU) • Supporting up to 768GB RDIMM/LRDIMM 2666 memory PCI Expansion Slots • (4) PCIe G3 x16 slots(#1, #3, #7) • (3) PCIe G3 x8 slot (#2, #4, #6) Network • (2) 1000BASE-T ports(Intel® 1350-AM2) Storage (14) SATA 6G w/Intel® RSTe 5.0 RAID support (w/2x 8-pin SATA DOM) (1) M.2 (2242/2260/2280 PCIe x4 from CPU) (1) M.2(2242 PCIe x4 from PCH) • (4) USB 3.0@ rear • Optional TPM 1.2 & 2.0 • AST2500 BMC with iKVM, IPMI and Redfish support • Optional 7.1 channel Audio
| S7100 Key Features |
|---|
The s7100 offers maximum expansion within a standard 12" x 13" SSI EEB: form factor:
Intel's Xeon SP CPUs have increased from the maximum TDP of the Boardwell-EP generation, now with a maximum TDP of 205W. with this in mind, the VRM of the s7100 motherboard has been designed to power the most demanding of the Xeon SP lineup.
Powered by an optional Realtek ALC892, the s7100 workstation motherboard offers 7.1 Channel HD Audio via internal header an on-board optical S/PDIF output.
Paired with a workstation or 3U chassis, the s7100 supports the use of four double wide GPU cards. Tyan maintains an AVL with the latest consumer and professional video cards and GPU accelerators on the market.
The s7100 provides multiple options for compact boot drive support in space constrained server chassis, including a pair of NVMe M.2 and another pair of SATA DOM ports with Pin-8 power support.
Featuring AMI Megarac firmware, the s7100 motherboard offers support for IPMI 2.0 with iKVM and DMTF Redfish management protocol.
The s7100 workstation motherboard provides 4 PCIe x16 slots, all of which are spaced far enough apart to accomodate double-wide VGA and GPU cards.
For More Details Contact us:
Sahasra Electronics Private Limited
Email: memory@sahasraelectronics.com
| Company Name | Sahasra Electronics |
| Category | Electronic Manufacturing Services |
| Sub Category | EMS |
| Activity | Assembly/ Sub-Assembly |
| Core Activity | Manufacturing |
| Location | NOIDA, UP |
| Operate across key sectors that include PCB Fabrication, EMS – PCBA, Wire Harness & Box Build, Memory Products & Solutions, Consumer and Enterprise IT Hardware, Semiconductor Packaging, Smart LED Lighting, and RFID solutions. Sahasra has pioneered technology, from Metal Core PCBs to Enterprise-Grade Mother Boards and Semiconductor Packaging, earning a reputation as a technology disruptor. Additionally, at SEPL we have set up state of the art IT Hardware Products manufacturing lines to cater to high end enterprise solutions. We carry the distinction of being the very first domestic company in India manufacturing Motherboards and Server Systems as well as Enterprise Grade SSD/Memory solutions for domestic and overseas customers. |
