backplane

Categories: Hardware Components

Open-VPX provides a versatile, high-speed architecture utilizing the rugged Eurocard form factor. There are backwards-compatibility options with VME/64x with hybrid backplanes. As VITA 65 (VITA 65.0 and VITA 65.1) OpenVPX backplanes are based upon specific configuration profiles, many designs are customized. However, Rug-Rel offers the 3U VPX configuration as off-the-shelf. Other VPX derivations include VITA 46 (base VPX), VITA 66 for optical, and VITA 67 for RF.

Rug-Rel components and systems pvt ltd

313, Service Road, Nagarbhavi 2nd Stage, Marilingappa Extension, Naagarabhaavi, Bengaluru, Karnataka 560072

Enquiry

Product Specification:

Key Features:  Compliant to VITA 46.0 baseline specification  OPEN VITA 65 Specification  Backplane Profile: BKP3-CEN03-15.2.9-n  3 Slots VPX, 1 Payload Slot, 2 Peripheral Slot  M3 studs power entry  Reference clock  Aux clock  System Management Interface (I2CA, I2CB)  Input current per backplane o VS1 = 28A o VS2 = 28A o VS3 = 30A

About the Company:

Company Name	Rug-Rel components and systems pvt ltd
Category	Hardware Components
Sub Category
Activity	Finished products
Core Activity	Manufacturing
Location	313, Service Road, Nagarbhavi 2nd Stage, Marilingappa Extension, Naagarabhaavi, Bengaluru, Karnataka 560072

Company Details:

Rug-Rel Components & Systems Pvt. Ltd. is specialized in design & development, manufacturing & integration and testing of electronic sub-systems and systems. We are a technology house of technically qualified and professionally experienced engineers with the strong know-how in the areas of embedded hardware & software, component engineering, manufacturing services, cable assembly & wire-harnessing and sub-system / system integration. Our expertise clusters around the industry-renowned bus architectures like VME64X, VXS, VPX, cPCI, mTCA and ATCA. Linked with these architectures we serve our customers, from the key market segments like Defence, Avionics, Transportation, Energy, Automation, Machinery & Robotics, Medical, Telecom, IOT and Automotive, with both standard and customized solutions. Our key strength lies in the design & manufacture of Motherboards & SBCs, architecture (VME, VXS, VPX, cPCI, mTCA & ATCA) based Backplane solutions and associated Systems, Customized Rack, Test jigs, Industrial & MIL-grade Panel PCs, Industrial & Rugged Monitors, Rugged Servers, Rackmount PCs, Box PCs, Cabinets, IND/MIL Grade Consoles and special electronic components like Connectors, RF Components, Fibre Optic Components, Cable Assemblies, etc.
